Mein Cubietruck

Ich möchte hier mal mein Cubietruck vorstellen ;)

Hardware Informationen:

  • AllWinnerTech SOC A20,ARM Cortex-A7 Dual-Core ARM Mali400 MP2 Complies with OpenGL ES 2.0/1.1
  • 1GB or 2GB DDR3@480MHz
  • HDMI&VGA 1080P display output on-board with ESD protectors
  • RTL8211E 10M/100M/1G Ethernet PHY
  • Build-in Wifi+BT wireless connection with antenna on-board BCM AP6210
  • Built-in IR receiver
  • SPDIF audio interface
  • SATA 2.0 interface support 2.5’ HDD,(for 3.5’ HDD, only need another 12V power input)
  • Storage solution: NAND+MicroSD or TSD+ MicroSD or 2*MicroSD
  • 2 x USB HOST,1 x OTG,1 x SPDIF,1 x IR,4 x LEDs,1 Headphone,3 x Keys
  • Power: DC5V @ 2.5A with HDD,support Li-battery & RTC
  • 54 extended pins including I2S, I2C, SPI, CVBS, LRADC x2,UART, PS2, PWMx2, TS/CSI, IRDA, LINEIN&FMIN&MICIN, TVINx4 with 2.0 pitch connectors
  • PCB size:11cm *8cm*1.4mm,very suitable for installing a 2.5’ HDD
  • Pre-installed Android 4.2.2 with full functionalities

weitere Informationen bekommt man hier: http://www.forum-cubieboard.de/Thread-cubietruck-hardware-details

Lieferumfang:

  • Cubietruck main board x1
  • SATA 2.0 cable x1
  • Mini USB to OTG x1
  • Mini USB cable x1
  • USB to 1.7 mm DC jack cable x1
  • Acrylic shell x1
  • Ultrathin Heat Sink x1

Bilder:

Cubietruck normal:

IMAG0471m

IMAG0472m

IMAG0473m

IMAG0476m

Cubietruck mit bei liegendem Acryl-Gehäuse:

IMAG0483m

IMAG0486m

Cubietruck mit bei liegendem Gehäuse und einer 2,5 HDD:

IMAG0493m
